Troughed Roller Bed Conveyor

Troughed Roller Bed Conveyor

RECYCLING OPERATIONS

The Model CRB is ideally used in scrap handling and recycling operations.

Troughed Roller Bed Conveyor
  • CRB Model - Troughed Roller Bed

    The Model CRB is ideally used in scrap handling and recycling operations. The roller bed with deep troughed construction can carry culled or broken glass, cans, wood chips, aluminum, steel, plastic stampings, etc. The CRB is widely used in recycling operations as an environmental conveyor.

    Roller bed with 2" dia. x 12 ga. unplated tread rollers spaced every 6" or 12" mounted in 10 ga. painted formed steel channel frame with 12 ga. painted side guards extending 8-1/2" above the belt. Sections bolt together with splice plates

    • Tread Rollers, 2" dia. x 12 ga. unplated rollers spaced every 6" or 12"
    • Overall Frame widths;, 18", 20", 22", 24", 28", 34"
    • End Drive Standard
    • Adjustable Floor Supports Available
    • Maximum load per linear ft. of conveyor 25 lbs. not to exceed rated capacities.
